Scalable Hydrogen Infrastructure with HPak Storage Modules
High-Density, 450 Bar Storage Solutions for Industrial and Mobile Pipeline Support
High-Density Reliability for On-Site Gas Management
The HPak Hydrogen Storage Modules are engineered to provide high-capacity, high-pressure gas storage for industrial applications where consistent supply and a compact footprint are critical. Designed for stationary or semi-permanent installation, these modules offer a service pressure of 450 bar (6,500 psig), serving as the essential high-pressure reservoir for refueling stations and industrial hubs.
By integrating 25 high-performance Type III cylinders into a single, modular unit, the HPak delivers the storage density required to manage peak demand. These modules are designed to pair seamlessly with the HySpenser system, acting as the primary storage bank that supplies the compressor/dispenser skid. Together, the HPak and HySpenser create a complete, turnkey infrastructure solution for high-flow gas distribution.
HPak Module Features
The HPak is built for heavy-duty industrial cycles, focusing on maximizing gas density while maintaining a manageable footprint for site integration.
-
Optimized for high-pressure storage, ensuring maximum gas density and compatibility with standard industrial compression systems.
-
Features a 25-cylinder configuration with a total water volume of 7,875 liters (315 liters per cylinder), providing a massive storage reservoir.
-
Capable of storing 225 kgs of Hydrogen, ensuring your operations have the necessary buffer to handle high-demand cycles.
-
A robust, engineered enclosure measuring 129" x 102" x 96", designed for stability and protection in demanding industrial environments.
-
Includes a centralized manifold system designed for high-flow connection to the HySpenser compressor/dispenser skid, allowing for rapid equalization and fueling.
Benefits of the HPak Series
H2 Manufacturing provides the HPak modules to empower industrial operators with a reliable, scalable storage solution that eliminates the need for expensive fixed infrastructure.
Total System Integration: When paired with the HySpenser, the HPak serves as a high-pressure buffer, allowing the compressor to operate at peak efficiency while maintaining a constant supply for the dispenser.
Maximized Site Density: The compact dimensional design allows for significant gas storage in a small physical area, ideal for sites with limited space or temporary deployment needs.
Reduced Logistical Complexity: With a 225 kg capacity per module, you can maintain a larger on-site gas reserve, reducing the frequency of deliveries and streamlining your mobile pipeline logistics.
Modular Scalability: Multiple HPak units can be paired together to create a custom storage system tailored to your specific industrial requirements.
Dive Deeper
Get all the technical details you need! Download our comprehensive HPak Hydrogen Storage Module specification sheet to explore performance data and available configurations.
Contact Us to Learn More
Ready to optimize your on-site hydrogen storage and fueling infrastructure? Contact H2 Manufacturing today to discuss how the HPak can empower your high-pressure operations.
Let our industrial gas specialists answer your questions and help you find the perfect storage configuration for your facility!
