QTV-352 Precision Ball Valve (350 Bar)

Engineered for Long-Term Industrial Endurance

The QTV-352 is a professional-grade, trunnion-style ball valve designed specifically for the rigorous demands of gaseous Hydrogen (GH2) and industrial gas distribution. Engineered as a compact and lightweight solution, this 1/4-turn valve provides high-flow performance with the added safety of an integrated Pressure Relief Device (PRD).

While optimized for hydrogen applications (ISO 14687), the QTV-352 is a versatile component built for consistent service with Natural Gas (CNG), Nitrogen, Helium, and Air. Whether integrated into multi-tank transport systems or stationary storage banks, the QTV-352 ensures zero-leak reliability and precision flow control in high-pressure environments.

QTV-352 Features

The QTV-series is built for sustained operational life, offering a 20-year life expectancy and the structural integrity required for high-cycle performance.

Features a built-in PRD with a standard trigger temperature of 102°C (216°F), providing critical protection for high-pressure cylinder systems.
Engineered with a 0.2812” thru-bore to provide steady, non-restrictive flow for filling and withdrawal in multi-cylinder configurations.
Rated for a Nominal Working Pressure (NWP) of 350 bar (5,075 psi), with a Maximum Working Pressure (MWP) of 438 bar and a burst rating exceeding 875 bar.
Offers an exceptional strength-to-weight ratio, reducing the overall mass of the manifold and transport system while maintaining heavy-duty performance standards.
Certified for reliable operation in environments ranging from -40°C to +85°C.

Benefits of the QTV-352 Ball Valve

H2 Manufacturing provides the QTV-352 to give system integrators and fleet operators a component that balances high flow capacity with uncompromising safety.

Optimized Flow Dynamics: With a flow capacity (Cv) of 2.08 on the inlet and 2.95 on the vent, this valve is designed for rapid filling and discharge cycles.
System Versatility: The -6 SAE (9/16”-18) I/O port and 1⅛”-12 UNF cylinder neck thread allow for seamless integration into standard industrial gas infrastructure.
Zero-Leak Performance: Precision-engineered to maintain a leakage rate of ≤ 10 Ncc/hr, ensuring the integrity of your gas supply and the safety of your facility.
Designed for Multi-Tank Integration: When used in systems with at least two active cylinders, the QTV-352 remains non-restrictive, maximizing the throughput of your mobile or stationary pipeline.

Dive Deeper

Get the technical specifications for your next project! Download the full QTV-Series data sheet for information.

Download Data Sheet

Contact Us to Learn More

Ready to integrate the QTV-352 into your high-pressure gas system? Contact H2 Manufacturing today to discuss port configurations, bulk ordering, and technical compatibility for your specific application. Let our valve specialists provide the precision components your infrastructure requires!
